automatic Toothbrush Making Machine/ Production Line

We can design the production line according to your requirements. The following data is just for your reference.

1. Brief Intrduction

Toothbrush machine line capacity: 125ton/year,
Each toothbrush weight is 20g,
Quantity/year is about 6250000pcs.

2. The toothbrush making machine line flow

Injection machine(make the toothbrush handle)→Fully-automatic toothbrush production line(plant bristle, cut bristle, grinding bristle) → Testing →Packing machine line

3. Manufacturing Scope

Part I: Brush handle production line
​

Mechanical rotary machine
machinery oil-way part:
1. high efficiency: 2-3s can be saved for one cycle time, which improves production efficiency.
2. high safety:Driving of rotary table, stable and smooth, inserts can slide easily; it has 3 level fixed position, quick, silent.
3. accurate manufacture
4. stable running:electric-hydraulic proportional flow valve with superelevation response
a. flow value will change along with rake ratio line at short time,which can ensure disk can change to low speed;
b. speed of disk can be improved to save time;
c. impact force is reduced, service life is lengthened;
d. controllable performance is improved;
5. higher speed:rotating is more light, mute, and accurate and more molarity room is added.
6. Double pump: asynchronous action can be proceeded at the same time, which improves efficiency and saves time and energy.
7. Lubrication system is adopted to prolong service life.
8. Prolong life-span device is setted up at mechanical axis and rational structure.
9. Oil-way with bi-proportion, which is high accuracy, easy operation.
10. space saving and labor saving

Part II: Fully- automatic toothbrush production line

Part III: Toothbrush test device

1. Testing machine for material tensile
1.2 programmable and constant temperature and humidity testing machine

Part IV: Packing line

Flat Blister Card Packing Machine

Back covering machine with automatic molding

Automatic box filler

For more information, please contact us at any time.
