Delivery time: 2 months after the payment.

Delivery method: wooden cases or nude cargo

Payment term: take USD 30% of the total price as advance payment by T/T and the balance should be paid by T/T before delivery.

Installation: the seller is responsible for installation and debugging. The whole installation, debugging and training will take about 30 days, and the seller will send 4 engineers to installation, and the installation fee is 100USD/day/person. The buyer is responsible for the round-trip airplane tickets, accommodation, medical treatment, safety and relative fees. In addition the buyers should assign 1 interpreter and 2 workers, electrical wire outside the box and tools for installation to cooperate with the work.

Equipment reference:

1. Automatic cotton plucker

​
Use and characteristics:
round automatic plucker is suitable for the plucking of all classes of raw cotton, cotton chemical fiber and middle-long fiber shorter than 76mm. It's the first procedure of the machine and consists of pulley, central axis, expansion tube and ground rail, etc. And external wall board. A002D is used singly. And the FA002 can be used in double. For large number of raw material varieties with great differences, FA002 improve the number of mixed bale and reduce the mixing units, helps to improve working quality.

Main specifications:
Production capacity: 800kg/h
Cotton piling weight: 2000kg
Beater rotating speed: 740r/min
Knife out of rib: 2.5-7.5mm
Crab slewing speed: 1.7;2.3r/min
Ground railer external diameter: 5192mm
Total height: 4155mm
General power: 3.8kw
Machine weight: about 1600kg

2. Mixing opener

​
Use and characteristics:
Suitable for all classes of raw cotton (usually for those with high maturity and higher class). Placed in the front of automatic plucker, and transmit the small block brought by the automatic plucker raw cotton into the machine with the aid of A045Dcondenser (additional), open and remove some impurities and dusts, then suck the raw cotton into the platform with its condenser.
​

Main parameters:

For more information, please contact us.
